ARES Plus

IMPROVED BATTERY LIFE

1000VA ~ 3000VA

ARES PLUS tower has got a number of smart features that increase battery life. Thanks to the new Battery Discharge protection control function, it’s perfect for medium voltage substations applications.

This product belongs to the Ablerex Single Phase Online system. Discover all the infos in the box below: features, options and accessories.

Brand Logo

Single Phase Online

Features

  • Online double conversion VFI protection from 1000VA to 3000VA
  • Extreme battery lifetime thanks to: - wide input voltage tolerance (110-300V) - wide input frequency tolerance (44-66Hz) - intelligent battery management
  • Battery discharge level control, settable 30-100% of the available capacity
  • Precise patented backup time estimation
  • 2 programmable IEC outlets plus two Schuko
  • Cold start to activate loads without mains
  • Multiple operation modes to maximize energy efficiency
  • Strong overload capability to improve CB’s selectivity
  • Manually activated extra service check
  • Firmware upgradable for updates and customization
  • Remote EPO and On/Off functions
  • RS232 and USB port, comm. slot
  • CEI 0-16 compliant

Options

  • USB card, RS485 card, dry contact relay card, SNMP/web card
  • Extra RS232 card
  • External battery cabinet
  • Different outlets
  • LED interface
  • Ares Plus 3000 version with 8 batteries
  • Remote On/Off without mains
